Turmera 4S 14.4V 16.8V 30A 40A BMS 18650 Lithium Battery Protect Board Balance With DC Plug for Electric Drill Screwdriver Batteries Use

Features:

The protection board is for 4 series Li-ion batteries, mainly used for electric power tools.

It uses special IC for 4S lithium batteries as processor to detect real-time voltage, charge and discharge current and ambient temperature of each battery.

Stable various protective functions for charging and discharging, such as overcharge protection, over-discharge protection and short circuit protection.

Low power consumption,the working current is about 25uA and quiescent current is about 6uA.

Choosing the correct protection board and applying it appropriately is vital to the longevity your batteries.

Specifications:

Charge Voltage:16.8V

Single Cell Charge Voltage:4.25V

Continuous Discharge Current: 30A/40A

Overcharge Single Cell Detection Voltage:4.25V

Overcharge Protection Delay:1S

Overcharge Single Cell Recovery Voltage:4.13V

Overcharge Protection Release Delay:1mS

Over-discharge Single Cell Detection Voltage:2.8V

Over-discharge Protection Delay:1S

Over-discharge Single Cell Recovery Voltage:2.5V

Over-discharge Protection Release Delay:100±20mS

Over-current Detection Voltage:0.1-0.4V

Over-current Detection Current: 30A/40A

Over-current Detection Delay:1S

Short Circuit Protection Support:Yes

Short Circuit Detection Delay:250uS

Short Circuit Release Delay:1S

Short Circuit Detection Voltage:0.8V

Recovery State:Auto after Disconnect Load

Over Temperature ProtectionProtection Temperature:70±5°

Recovery Temperature:55±5°

Working State:25uA (25°)

Stand-by State:6uA(25°)

Discharge Main Circuit Internal Resistance:30±5mΩ

Operating Temperature: -40°-85° RH≤75%

Store Temperature: -40°-125° RH≤75%

Notice:

1.Please choose the BMS which fit for your Screwdriver Battery Use,like measure the BMS size or the discharge current of your battery need.

2.Dimension may have an error range,please understanding for this.

3.Due to the color of the protection board may be updated during the production process, the color(may have Green/Red/Black or others) of the protection board of the same model may change due to different production batches. This is normal and we will ship it randomly.

Packing List: Shipping by Choose Different Bundle.
