Enhance the flexibility and efficiency of your industrial applications by choosing our customizable industrial cameras! Whether it’s the housing design, cable length, lens specifications, or special features, this camera can provide you with tailored solutions.
Note: The 10x zoom defaults to 6-60mm CS Mount lens
You can contact customer service to select the Lens you want, such as CS Mount Lens, M12 Mount Lens
CS Lens option: 2.8mm,4mm,6mm,8mm,12mm,16mm,25mm,2.8-12mm,3.6-10mm,5-50mm,6-60mm,5-100mm
WGWK 4K Mini POE IP Camera CMOS Sensor Security Industrial CCTV Video 3/4/5/8MP Metal Box Network Camera with 6mm 2.8-12mm Lens
Note: Supports replacement of filters of other specifications. Available models include Narrowband 650nm/740nm/780nm/808nm/850nm/905nm/940nm/980nm, 700nm long wave pass, Infrared 650nm/850nm/940nm
If you need it, please contact customer service in time!
Contact customer service to change the color of the camera housing (black)
And get a free camera stand when you purchase two or more
Superior image quality and flexibility for your surveillance system
This mini camera is ideal for precise monitoring. It combines high resolution, zoom lens and convenient POE power supply technology to help you easily achieve remote HD monitoring.
3/4/5/8MP HD resolution: Provides ultra-clear, detailed images to ensure that every corner of the surveillance can be accurately captured.
2.8-12mm zoom lens: Flexible adjustment of focal length to achieve accurate monitoring at close or long distances to meet the needs of different scenarios.
POE 48V power supply: Direct power supply through Ethernet cable, simplifying wiring work, reducing installation costs, and improving stability.
Strong durability: High-quality materials and design ensure stable operation of the device in various environments.
Whether indoors or outdoors, this mini camera can provide excellent visual effects for your security system and easily meet your high-quality monitoring needs.
Why H.265?
H.265 is a new video coding standard that delivers higher-quality network video with limited bandwidth, requiring only half the original bandwidth to play the same quality video.
Specification | 3/4/5/8MP | ||
System structure | Embedded RTOS design, dual-core 32-bit DSP(NT98566), pure hard compression | ||
Sensor | 8MP black light CMOS sensor; Color 0.0001Lux@F1.2, black and white 0.0001Lux@F1.2 | ||
Video processing | H265AI/H.265+(compatible with H.265/H.264) encoding, dual stream, AVI format; | ||
Image output | Main stream: 8MP 3840*2160@15fps; 5MP 2880*1616@25fps;4MP 2560*1440@25fps;3MP 2304*1296@25fps;2MP 1920*1080@25fps; | ||
Shutter | 1/50(1/60) second to 1/10,000 second | ||
Lens | Focal length and zoom lens, optional (2.8mm/4mm/6mm/8mm/12mm/16mm/25mm/2.8-12mm/3.6-10mm/5-50mm/6-60mm/5-100mm) | ||
Day-night switching mode | Support IR-CUT, IR-CUT coil internal resistance of 20 Ohm, power duration less than 200ma, voltage 3.5V-6V | ||
Noise reduction | Support 2D/3D noise reduction | ||
Wide dynamic | Supports digital wide dynamic | ||
Audio processing | G.711A COdec standard, supporting audio and video synchronization | ||
Audio interface | 1 input, level 2Vp-p, resistance 1kΩ, support pickup input; 1 channel output, resistance 16kΩ, 30mw output power, support to connect headphones or public amplifier | ||
Network interface | 1 RJ45 Ethernet interface, 10/100M adaptive; Support network protocols such as RTSP/FTP/DHCP/NTP/UPnP (combined with power interface) | ||
Signal interface | 1 photoresistor interface, 1 IR-CUT driver interface, support photoresistor input signal and IR-CUT, infrared lamp linkage | ||
Intelligent analysis | Supports humanoid detection, face detection, and customization of other intelligent functions | ||
Business function | Support WEB configuration, OSD, motion detection; Mobile detection alarm center reminder, screen pop-up linkage; Support MJPEG capture; Support client remote monitoring software, MYEYE platform and other system applications; Provide complete SDK development kit | ||
ONVIF protocol | support | ||
Mobile phone surveillance | Support mobile monitoring (iOS, Android) | ||
Power source | Power supply DC12V/2A, power consumption ≤3W | ||
Plate size | 38mm*38mm | ||
Instructions | Support POE power supply, light board drive voltage at 3.3V | ||
Rreliability | Comprehensive lightning protection, in line with national and international standards; 7*24 hours -10℃~65℃ high temperature test stable and reliable (including the whole machine test) | ||
About RTSP
Address stream:
Enter the network URL in Please enter network URL:
rtsp://10.6.3.57:554/user=admin&password=&channel=1&stream=0.sdp?
10.6.3.57 This is the IP of the connected device
:554 This is the port number of the RTSP service, which can be changed in the device’s network service
user=admin This is the login user name for the device
password= Password blank
channel=1 First channel
stream=0.sdp？Main code stream
stream=1.sdp？Auxiliary code stream
rtsp://192.168.1.10:554/user= admin&password=&channel=1&stream=0.sdp?
rtsp://10.6.3.57:554/user=admin&password=&channel=1&stream=0.sdp?
10.6.3.57 is the device IP address
:554 is RTSP port，can reset in device network service
user=admin is device user’s name
password= no pass word
channel=1 refer to Channel No.1
stream=0.sdp？ mainstream
stream=1.sdp？ substream
About computer operation and use
Make sure the camera is connected to the power supply and network
(the signal light flashes to prove that everything is normal)
Step 1 : Install VMS
VMS Computer Client: //download.xm030.cn/d/MDAwMDE2OTA=
Step 2: Login VMS
UserName: admin,Password:admin
Step 3: Find your camera and add
APP download: Search XMEye in Apple Store
